Haixing Power Engineering Co., Ltd. has a variety of gas generator sets, including Zichai (300 series, Z170 series, Z6150 series), Cummins, Shengdong, Tongchai and other gas generator sets.
The Z170 series gas engine uses the ignition system produced by ALTRONIC, the American company, and the cylinder head, piston and gas supply system are designed to make the gas burn more fully in the cylinder. At the same time, electronic speed regulator, pressure reducing valve, pressure regulating valve, mixer and other components are installed to make the system run more reliable.
project | Specification data | ||||
Unit model | Z6170ZLD/Z | Z6170ZLD/Z-1 | Z8170ZLD/Z | Z8170ZLD/Z-1 | |
Z6170ZLD/T | Z6170ZLD/T-1 | Z8170ZLD/T | Z8170ZLD/T-1 | ||
Generator model | 200GFZ | 250GFZ | 300GFZ | 400GFZ | |
200GFT | 250GFT | 300GFT | 400GFT | ||
Rated power (KW) | 200 | 250 | 300 | 400 | |
Current (A) | 361/187 | 451/234 | 541/281 | 722/374 | |
Voltage (V) | 400 / 690 | ||||
Rated frequency (Hz) | 50Hz | 60Hz | |||
Rated speed (r/min) | 1000 | 1500 | 1000 | 1500 | |
Power factor (cosφ) | 0.8 (Lag) | ||||
Gas heat consumption rate MJ/(kW·h) | 10.5～11.5 | ||||
Oil consumption rate g/(kW·h) | ≤1.0 | ||||
Phase number and connection method | Three-phase and four-wire system | ||||
Excitation method | Brushless excitation | ||||
Starting method | Compressed air start or electric motor start | ||||
Dimensions (L×B×H) (mm) | 4000×1400×2200 | 4500×1400×2200 | |||
Net mass (kg) | 6200 | 7600 | |||
