The Haixing/Cummins series diesel generator set uses the Sino-US joint venture BNK series engine as the engine. Its reliable performance and low usage cost have always won the trust of military industrial and mining enterprises. Cummins Company, Cummins Company was founded in 1919 and is headquartered in Columbus, Indiana, USA. Cummins has more than 680 distributors in 137 countries and regions, and has more than 500 service outlets all over the world. As a foreign investment in the generator industry, Cummins owns manufacturing companies such as Chongqing Cummins Automobile Co., Ltd. and Dongfeng Cummins Automobile Co., Ltd., and produces it according to Cummins' unified quality standards. Through Cummins and Cummins' service network, it provides users with fast service guarantees.
| Unit model | Output power (KW/KVA) | Diesel engine model | Diesel engine power main/standby (KW) | Number of cylinders | Bore/stroke (mm) | Displacement (L) | Engine oil capacity (L) | Fuel consumption | Unit size L*W*H(mm) | Unit weight (kg) | |
| HX-30GF | 30 | 37.5 | 48T3.9-G2 | 36/40 | 4 | 102/120 | 3.9 | 11 | 209 | 1700×750×1200 | 720 |
| HX-50GF | 50 | 62.5 | 40TA3.9-G2 | 55/60 | 4 | 102/120 | 3.9 | 11 | 209 | 1800×750×1200 | 800 |
| HX-75GF | 75 | 93.75 | 6875.9-G1/G2 | 92/110 | 6 | 102/120 | 5.9 | 16.4 | 210 | 2200×800×1300 | 1180 |
| HX-100GF | 100 | 125 | 68TA5.9-G2 | 110/121 | 6 | 102/120 | 5.9 | 16.4 | 210 | 2250×830×1300 | 1200 |
| HX-120GF | 120 | 150 | 6BTAA5.9-G2 | 120/132 | 6 | 102/120 | 5.9 | 16.4 | 206 | 2250×830×1350 | 1300 |
| HX-150GF | 150 | 187.5 | 6CTA8.3-G2 | 163/180 | 6 | 114/135 | 8.3 | 20 | 206 | 2500×860×1400 | 1800 |
| HX-180GF | 180 | 225 | 6CTAA83-G2 | 183/204 | 6 | 114/136 | 83 | 20 | 207 | 2600×880×1500 | 2100 |
| HX-200GF | 200 | 250 | 6LTAA8.9-G2 | 220/245 | 6 | 114/140 | 8.9 | 20 | 206 | 2600×900×1500 | 2300 |
| HX-200GF | 200 | 250 | NT855-GA | 231/254 | 6 | 140/152 | 14 | 38.6 | 206 | 3000×1020×1750 | 2600 |
| HX-250GF | 250 | 312.5 | NTA856-G1A | 264/291 | 6 | 140/152 | 14 | 38.6 | 206 | 3100×1020×1750 | 2700 |
| HX-300GF | 300 | 375 | NTA855-G2A | 312/343 | 6 | 140/152 | 14 | 38.6 | 206 | 3200×1020×1750 | 2800 |
| HX-350GF | 350 | 437.5 | NTAA855-G7A | 407 | 6 | 140/152 | 14 | 38.6 | 206 | 3300×1450×1700 | 3000 |
| HX-360GF | 300 | 450 | KTA19-33 | 403/448 | 6 | 159/159 | 16.9 | 50 | 200 | 3400×1250×1970 | 3250 |
| HX-400GF | 400 | 500 | KTA19-G4/G3A | 448/504 | 6 | 159/159 | 18.9 | 50 | 203 | 3400×1250×1970 | 3400 |
| HX-450GF | 450 | 5625 | KTAA19-G6 | 470/555 | 6 | 150/159 | 15.9 | 50 | 203 | 3400×1300×1970 | 3600 |
| HX-500GF | 500 | 625 | KTAA19-G6A | 554/610 | 6 | 159/159 | 18.9 | 50 | 203 | 3600×1400×1970 | 4200 |
| HX-500GF | 500 | 625 | KTA19-G8 | 575 | 6 | 159/159 | 11.9 | 50 | 203 | 3400×1300×1970 | 4200 |
| HX-630GF | 630 | 788 | KTA38-G2 | 664/731 | 12 | 159/159 | 37.8 | 135 | 201 | 4470×1700×2200 | 7200 |
| HX-800GF | 800 | 1000 | KTA38-G2A | 813/895 | 12 | 159/159 | 37.8 | 135 | 196 | 4600×1800×2200 | 7600 |
| HX-880GF | 880 | 1100 | KTA38-G5 | 880/970 | 12 | 159/159 | 37.8 | 135 | 196 | 4600×1800×2200 | 7800 |
| HX-1000GF | 1000 | 1250 | KTA38-G9 | 1069 | 12 | 159/159 | 37.8 | 135 | 196 | 4800×1800×2300 | 8200 |
| HX-1200GF | 1200 | 1500 | KTA50-G3 | 1227 | 16 | 159/159 | 50.3 | 177 | 198 | 5150×2000×2300 | 8400 |
| HX-1250GF | 1250 | 1563 | KTA50-G8 | 1429 | 16 | 159/159 | 50.3 | 177 | 196 | 5200×2000×2300 | 8800 |
| HX-1500GF | 1500 | 1875 | QSK60-G3 | 1615/1790 | 16 | 159/190 | 60 | 280 | 192 | 6175×2287×2537 | 14800 |
| HX-1600GF | 1600 | 2000 | QSK60-G4 | 1730/1915 | 16 | 159/190 | 60 | 280 | 194 | 6175×2287×2537 | 15000 |
| HX-1800GF | 1800 | 2250 | OSK60-G8 | 1942/2145 | 16 | 159/190 | 60 | 280 | 194 | 6175×2287×3116 | 17000 |
| HX-2000GF | 2000 | 2500 | QSK78-G6 | 2400/2660 | 18 | 170/190 | 77.6 | 466 | 192 | 7158×2250×2535 | 25000 |
