1. Introduction to Chongqing Cork Company
Chongqing Cork Engine Technology Co., Ltd. is an engine project invested in China by GOOGOL POWER-TECH Co., LTD., an integrated enterprise involving engine manufacturing and energy development. The company is headquartered in Nevada, the United States. The company's registered address is Plaza Vegas, 3305 West Spring Mountain Rd, #48, Las Vegas, Nevada 89102, USA.
Chongqing Cork Engine Technology Co., Ltd. is registered in Yongchuan District, Chongqing. The company was established in 2006. The company covers an area of 200,000 square meters and the planned production workshop area is 120,000 square meters. After full production, the annual output of diesel engines will reach 100,000 units.
Currently, there are two series of Cork series diesel engines: P and Q. The engine's power output range is 300-3000KW, the cylinder bore range is 128-170mm, and the number of cylinders is 6-20 cylinders. The use areas of Cork engine are: generator sets, mining machinery, ship power and various industrial power machinery.
2. Main parameters
Unit model | Unit power (KW) | Current (A) | Engine model | Engine power (KW) | Number of cylinders | ||
spare | Commonly used | spare | Commonly used | ||||
HX200GF | 220 | 200 | 360 | PTA780-G1A | 253 | 231 | 6 |
HX250GF | 275 | 250 | 450 | PTA780-G1C | 313 | 286 | 6 |
HX280GF | 310 | 280 | 504 | PTA780-G3 | 351 | 321 | 6 |
HX300GF | 330 | 300 | 540 | PTA780-G5 | 373 | 340 | 6 |
HX320GF | 360 | 320 | 576 | PTAA780-G1 | 405 | 362 | 6 |
HX360GF | 400 | 360 | 648 | PTAA780-G3 | 449 | 405 | 6 |
HX600GF | 660 | 600 | 1080 | QTA2160-G1A | 734 | 670 | 8V |
HX640GF | 704 | 640 | 1152 | QTA2160-G1B | 781 | 713 | 8V |
HX750GFB | 800 | 728 | 1310 | QTA2160-G1C | 883 | 806 | 8V |
HX800GF | 880 | 800 | 1440 | QTA2160-G1 | 968 | 883 | 8V |
HX850GF | 935 | 850 | 1530 | QTA2160-G3 | 1027 | 936 | 8V |
HX900GF | 1000 | 900 | 1620 | QTA2160-G5 | 1100 | 1004 | 8V |
HX1000GF | 1120 | 1000 | 1800 | QTA3240-G1 | 1219 | 1093 | 12V |
HX1200GF | 1340 | 1200 | 2160 | QTA3240-G5 | 1451 | 1303 | 12V |
HX1365GF | 1500 | 1365 | 2457 | QTA3240-G7 | 1608 | 1467 | 12V |
HX1500GF | 1650 | 1500 | 2700 | QTA4320-G1 | 1777 | 1621 | 16V |
HX1800GF | 1800 | 1640 | 3240 | QTA4320-G3 | 1933 | 1766 | 16V |
HX2000GF | 2000 | 1800 | 3600 | QTA4320-G5 | 2141 | 1933 | 16V |
Unit model | Bore ╳ stroke (mm) | Exhaust volume (L) | Engine oil capacity L | Load fuel capacity | Speed regulation method | Unit weight | Unit appearance net size | |
HX200GF | 128 | 166 | 12.8 | 40 | 55.53 | electronic | 2300 | 3150×1230×1436 |
HX250GF | 128 | 166 | 12.8 | 40 | 68.58 | electronic | 2380 | 3150×1230×1436 |
HX280GF | 128 | 166 | 12.8 | 40 | 76.93 | electronic | 2500 | 3150×1230×1436 |
HX300GF | 128 | 166 | 12.8 | 40 | 81.62 | electronic | 2550 | 3150×1230×1436 |
HX320GF | 128 | 166 | 12.8 | 40 | 86.84 | electronic | 2600 | 3150×1230×1436 |
HX360GF | 128 | 166 | 12.8 | 40 | 97.27 | electronic | 2650 | 3250×1230×1436 |
HX600GF | 170 | 195 | 35.4 | 160 | 152.52 | electronic | 6750 | 4400×2190×2290 |
HX640GF | 170 | 195 | 35.4 | 160 | 162.21 | electronic | 6820 | 4500×2190×2290 |
HX750GFB | 170 | 195 | 35.4 | 160 | 181.58 | electronic | 7150 | 4500×2190×2290 |
HX800GF | 170 | 195 | 35.4 | 160 | 198.82 | electronic | 7350 | 4500×2190×2290 |
HX850GF | 170 | 195 | 35.4 | 160 | 210.80 | electronic | 7650 | 4600×2190×2290 |
HX900GF | 170 | 195 | 35.4 | 160 | 226.07 | electronic | 7850 | 4600×2190×2290 |
HX1000GF | 170 | 195 | 53.1 | 180 | 246.01 | electronic | 9000 | 5100×2190×2740 |
HX1200GF | 170 | 195 | 53.1 | 180 | 288.71 | electronic | 10500 | 5400×2190×2740 |
HX1365GF | 170 | 195 | 53.1 | 180 | 325.00 | electronic | 10800 | 5400×2190×2740 |
HX1500GF | 170 | 195 | 70.8 | 240 | 364.86 | electronic | 12800 | 5800×2600×2800 |
HX1800GF | 170 | 195 | 70.8 | 240 | 393.46 | electronic | 13200 | 5800×2600×2800 |
HX2000GF | 170 | 195 | 70.8 | 240 | 428.27 | electronic | 13500 | 6000×2600×2800 |
